RIGOL Chapter 2 Front Panel Operations
2-22 DP800 User’s Guide
Recorder
When the recorder is enabled, users can record the current state of the instrument
and if analyzer is installed, users can also analyze the file recorded.
Press Recorder to open the recorder setting interface. You can turn on or
off the recorder function, set the record period and select the store destination.
1. Switch
Press Switch to turn on or off the recorder and the default is “Off”. When the
recorder is turned on, the record period and destination cannot be set. The
instrument samples and records the output of each channel according to the
current record period. When the recorder is turned off, the current record is
finished and the instrument prompts you to save the file recorded (press OK to
save the file).
Note: During the record, make sure that the output of each channel is enabled;
otherwise, the record data will be 0.
2. Record Period
The record period is the time interval at which the instrument samples and
records the output of each channel when the recorder is turned on. Press
Period and use the numeric keyboard or direction keys and knob to set the
record period of the recorder. The range is from 1s to 99999s and the default is
1s.
3. Destination
Before turning on the recorder, select the store destination. Press Dest to enter
the store and recall interface and the file type is fixed at “*.rof”. You can store
the file recorded in internal or external memory. After selecting the desired
destination, press Save, input the desired filename and press OK (for the
detailed operations, refer to the introduction in “
Store and Recall”). After
finishing the record, the instrument stores the record file with the specified
filename to the specified destination.
