RIGOL Chapter 1 Quick Start
1-4 DP800 User’s Guide
Front Panel
The front panel of DP800 is as shown in Figure 1-3. This section gives a brief
introduction of the function of each part at the front panel.
Figure 1-3 Front Panel
1 2 3 4
11 10 9 8 7 6 5
