RIGOL Chapter 1 Quick Start
1-22 DS4000E User’s Guide
Table 1-2 User Interface Overview
No. Name No. Name
1 Auto Measurement Items 9 Trigger Setting
2 Analog Channel Label and
Waveform
10 CH1 Status Label
3 Status 11 CH2 Status Label
4 Horizontal Time Base 12 CH3 Status Label
5 Sample Rate and Memory Depth 13 CH4 Status Label
6 Waveform Memory 14 Message Box
7 Trigger Position 15 Notification Area
8 Horizontal Position 16 Function Setting Menu
Tip: Table 1-2 is the user interface overview table. You can click the number or name
to quickly move to the corresponding content.
In the following part, detailed introductions are provided on the user interface
accoding to the numbering sequence in Figure 1-14.
1. Auto Measurement Items
Provide 16 horizontal (HORIZONTAL) and 13 vertical (VERTICAL) measurement
parameters. Pressing MENU at the left of the screen can unfold the horizontal
measurement menu or the vertical measurement menu or fold the
measurement menu. When the measurement menu is unfolded, pressing the
measurement menu softkey at the left of the screen can activate the auto
measurement function of the corresponding parameter.
Note: When the measurement menu is unfolded, the following labels may be
displayed in the grid at the lower-left side of the screen.
Denote that the current menu includes multiple pages. You can press
(the page down key) at the left of the screen to open the next page
of menu.
Denote that the current menu includes multiple pages. You can press
(the page up key) at the left of the screen to open the previous page
of menu.
2. Analog Channel Label and Waveform
Different channels are marked in different colors. The channel label and
waveform are marked in the same color as the analog channel.
