RIGOL Front Panel Key Reference
2-18 User’s Guide for DSA1000 Series
2.1.3.10 Correction
Corrects the amplitude in order to compensate for the gain or loss from peripheral
equipment such as Antenna, Cable, and so on. When using this function, you can view
the correction parameters through a table and save or load the correction factors
during editing. When Correction is On, both the trace and related measurement
results will be corrected, and an icon
is shown on the left of screen.
1. Select
Chooses a correction factor from Antenna, Cable, Other or User for the current
correction. All related frequency and amplitude corrections will be displayed to
compensate for external gains or losses, the default is Off.
2. Correction
Enables or disables the amplitude correction, the default is Off. When you enable
the Correction, the system starts correcting the amplitude with a specified factor.
If more factors are added, all related data will be used for amplitude correction.
3. Edit
Sets or modifies the frequency and amplitude of correction factor. You can modify
this parameter using the numeric keys, knob, or direction keys. See table below:
Table 2-11 Edit menus of Amplitude correction
Menu Explanation
Point Create or set desired data point for correction factor
Range: 1 to 200
Frequency Set the frequency of specified point
Amplitude Set the amplitude correction of specified point
Range: -120 dB to 100 dB
Del Point Delete the specified point data: frequency and amplitude
correction.
4. Freq Interp
Selects the correction type to Lin or Log. In type of Lin, the frequency and
amplitude separately uses a Lin and Log unit to do interpolation; in type of Log,
both of parameters use a Log unit.
