Rigol DSA815 User Manual

RIGOL Chapter 2 Front Panel Operation
User’s Guide for DSA800/E Series
2-82
Table 2-54 Volume
Parameter Explanation
Default 100
Range 0 to 255
Unit N/A
Knob Step 10
Direction Key Step 20
3. Demod Time
Set the time for the analyzer to complete a signal demodulation after each
sweep. If Earphone is set to “On”, you will hear the demodulated signal
through the earphone during the demodulation. You can use the numeric keys,
knob or direction keys to modify this parameter. For more details, please refer
to “
Parameter Setting”.
Table 2-55 Demod Time
Parameter Explanation
Default 100 ms
Range
5 ms to 1 ks
Unit
ks, s, ms, us, ns, ps
Knob Step 5 ms to 10 ms, step=0.1ms
10 ms to 100 ms, step = 1 ms
100 ms to 1 s, step = 10 ms
1 s to 10 s, step = 100 ms
10 s to 100 s, step = 1 s
100 s to 1 ks, step = 10 s
Direction Key Step in 1, 2, 5 sequence
4. Signal Gain
Set the signal gain to adjust the signal energy. When the signal amplitude is
small, the better demodulation effect can be obtained by adjusting the gain
value. You can use the numeric keys, knob or direction keys to modify this
parameter. For more details, please refer to "Parameter Setting".

Rigol DSA815 Specifications

General

Frequency Range	9 kHz to 1.5 GHz
Input Impedance	50 Ω
Input Connector	N-type female
Weight	4.25 kg
Power Supply	100-240 V AC, 50/60 Hz
Phase Noise	-80 dBc/Hz @ 10 kHz offset
Amplitude Accuracy	±1.5 dB
Display	8 inch LCD (800x480 pixels)
Video Bandwidth (VBW)	1 Hz to 3 MHz
Maximum Input Level	+20 dBm
Interfaces	USB, LAN
Resolution Bandwidth (RBW)	100 Hz to 1 MHz
Dimensions	361 mm x 178 mm x 128 mm
