Chapter 5 Specifications RIGOL
User’s Guide for DSA800/E Series
5-11
Tracking Generator (Option)
TG Output
DSA815 DSA832 DSA875 DSA832E
Frequency range
100 kHz to
1.5 GHz
100 kHz to
3.2 GHz
100 kHz to
7.5 GHz
100 kHz to
3.2 GHz
Output level range
-20 dBm to
0 dBm
-40 dBm to 0 dBm
Output level resolution 1 dB
Output flatness
relative to 50 MHz
±3 dB (nom.)
Trigger
Trigger
Trigger source free run, video, external
External trigger level 5 V TTL level
SSC-DSA (Option) (Only for DSA815)
Signal Seamless Capture (SSC)
Measurement bandwidth 1.5 MHz

Rigol DSA815 Specifications

General

Frequency Range	9 kHz to 1.5 GHz
Input Impedance	50 Ω
Input Connector	N-type female
Weight	4.25 kg
Power Supply	100-240 V AC, 50/60 Hz
Phase Noise	-80 dBc/Hz @ 10 kHz offset
Amplitude Accuracy	±1.5 dB
Display	8 inch LCD (800x480 pixels)
Video Bandwidth (VBW)	1 Hz to 3 MHz
Maximum Input Level	+20 dBm
Interfaces	USB, LAN
Resolution Bandwidth (RBW)	100 Hz to 1 MHz
Dimensions	361 mm x 178 mm x 128 mm
