Rigol DSA815 User Manual

RIGOL Chapter 5 Specifications
User’s Guide for DSA800/E Series
5-12
Input /Output
Front Panel Connectors
RF input
impedance 50 Ω (nom.)
connector N female
Tracking generator
output
impedance 50 Ω (nom.)
connector N female
Internal/ External Reference
Internal reference
frequency 10 MHz
output level +3 dBm to +10 dBm, +8 dBm (typ.)
impedance 50 Ω (nom.)
connector BNC female
External reference
frequency 10 MHz ± 5 ppm
input level 0 dBm to +10 dBm
impedance 50 Ω (nom.)
connector BNC female
External Trigger Input
External trigger
input
impedance 1 kΩ (nom.)
connector BNC female
Communication Interface
USB host
connector A plug
protocol version2.0
USB device
connector B plug
protocol version2.0
LAN
LXI core
2011 device
10/100Base, RJ-45
IEC/IEEE (GPIB) bus (USB-GPIB
option)
IEEE488.2

Rigol DSA815 Specifications

General

Frequency Range	9 kHz to 1.5 GHz
Input Impedance	50 Ω
Input Connector	N-type female
Weight	4.25 kg
Power Supply	100-240 V AC, 50/60 Hz
Phase Noise	-80 dBc/Hz @ 10 kHz offset
Amplitude Accuracy	±1.5 dB
Display	8 inch LCD (800x480 pixels)
Video Bandwidth (VBW)	1 Hz to 3 MHz
Maximum Input Level	+20 dBm
Interfaces	USB, LAN
Resolution Bandwidth (RBW)	100 Hz to 1 MHz
Dimensions	361 mm x 178 mm x 128 mm
