Chapter 5 Specifications RIGOL
User’s Guide for DSA800/E Series
5-13
General Specifications
Display
Type TFT LCD
Resolution 800 x 480 pixels
Size 8 inch
Colors 64k
Printer Supported
Protocol PictBridge
Mass Memory
Mass memory
flash disk (internal),
USB storage device (not supplied)
Power Supply
Input voltage range, AC 100 V to 240 V (nom.)
AC supply frequency 45 Hz to 440 Hz
Power consumption
35 W (typ.),
max. 50 W with all options
Environmental
Temperature
operating
temperature range
0℃ to 50℃
storage temperature
range
-20℃ to 70℃
Humidity
0℃ to 30℃
≤ 95% rel. humidity
30℃ to 40℃
≤ 75% rel. humidity
Altitude operating height up to 3,000m

Rigol DSA815 Specifications

General

Frequency Range	9 kHz to 1.5 GHz
Input Impedance	50 Ω
Input Connector	N-type female
Weight	4.25 kg
Power Supply	100-240 V AC, 50/60 Hz
Phase Noise	-80 dBc/Hz @ 10 kHz offset
Amplitude Accuracy	±1.5 dB
Display	8 inch LCD (800x480 pixels)
Video Bandwidth (VBW)	1 Hz to 3 MHz
Maximum Input Level	+20 dBm
Interfaces	USB, LAN
Resolution Bandwidth (RBW)	100 Hz to 1 MHz
Dimensions	361 mm x 178 mm x 128 mm
