Rigol DSA815 User Manual

RIGOL Chapter 5 Specifications
User’s Guide for DSA800/E Series
5-10
Spurious Response
Spurious response, inherent
DSA815 DSA832 DSA875 DSA832E
input terminated 50 Ω, attenuation = 0 dB, 20
℃
to
30℃
<-88dBm (typ.) <-90dBm*, <-100dBm (typ.)
Intermediate frequency <-60 dBc
System related sidebands
referenced to local oscillators, referenced to A/D
conversion, referenced to subharmonic of first LO,
referenced to harmonic of first LO
<-60 dBc
Input related spurious
mixer level = -30dBm
<-60 dBc
Sweep
Sweep
DSA815 DSA832 DSA875 DSA832E
Sweep
time
span ≥ 100 Hz 10 ms to 1500 s
1 ms to
3200 s
1 ms to
7500 s
1 ms to
3200 s
zero span 20 μs to 1500 s
20 μs to
3200 s
20 μs to
7500 s
20 μs to
3200 s
Sweep
time
uncertainty
span ≥ 100 Hz 5% (nom.)
zero span
(sweep time
setting
value > 1 ms)
5% (nom.)
Sweep mode continuous, single
Note: * Except the internal local oscillator (1820 MHz) and its harmonics.

Rigol DSA815 Specifications

General

Frequency Range	9 kHz to 1.5 GHz
Input Impedance	50 Ω
Input Connector	N-type female
Weight	4.25 kg
Power Supply	100-240 V AC, 50/60 Hz
Phase Noise	-80 dBc/Hz @ 10 kHz offset
Amplitude Accuracy	±1.5 dB
Display	8 inch LCD (800x480 pixels)
Video Bandwidth (VBW)	1 Hz to 3 MHz
Maximum Input Level	+20 dBm
Interfaces	USB, LAN
Resolution Bandwidth (RBW)	100 Hz to 1 MHz
Dimensions	361 mm x 178 mm x 128 mm
