Rigol DSA815 User Manual

RIGOL Chapter 5 Specifications
User’s Guide for DSA800/E Series
5-4
Amplitude
Measurement Range
Range
f
c
≥ 10 MHz
DANL to +20 dBm
Maximum Input Level
DC voltage 50 V
CW RF power
attenuation = 30 dB
+20 dBm (100 mW)
Max. damage level* +30 dBm (1 W)
Displayed Average Noise Level (DANL)
DSA815
Frequency
attenuation = 0 dB, RBW = VBW = 100 Hz, sample
detector, trace average ≥ 50, tracking generator off,
20℃ to 30℃, input impendence = 50 Ω
PA
off
100 kHz to 1 MHz <-90 dBm, <-110 dBm (typ.)
1 MHz to 1.5 GHz <-110 dBm + 6 × (f/1 GHz) dB, <-115 dBm (typ.)
PA
on
100 kHz to 1 MHz <-110 dBm, <-130 dBm (typ.)
1 MHz to 1.5 GHz <-130 dBm + 6 × (f/1 GHz) dB, <-135 dBm (typ.)
Note: *When f
c
≥ 10 MHz, input level > +25 dBm and PA is Off, the protection switch will be on.

Rigol DSA815 Specifications

General

Frequency Range	9 kHz to 1.5 GHz
Input Impedance	50 Ω
Input Connector	N-type female
Weight	4.25 kg
Power Supply	100-240 V AC, 50/60 Hz
Phase Noise	-80 dBc/Hz @ 10 kHz offset
Amplitude Accuracy	±1.5 dB
Display	8 inch LCD (800x480 pixels)
Video Bandwidth (VBW)	1 Hz to 3 MHz
Maximum Input Level	+20 dBm
Interfaces	USB, LAN
Resolution Bandwidth (RBW)	100 Hz to 1 MHz
Dimensions	361 mm x 178 mm x 128 mm
