Chapter 5 Specifications RIGOL
User’s Guide for DSA800/E Series
5-5
Displayed Average Noise Level (DANL)
DSA832 DSA875
Frequency
attenuation = 0 dB, RBW = VBW = 10 Hz, sample
detector, trace average ≥ 50, tracking generator off,
20℃ to 30℃, input impendence = 50 Ω
PA
off
9 kHz to 100 kHz <-110 dBm (typ.) <-110 dBm (typ.)
100 kHz to 5 MHz
<-125 dBm,
<-128 dBm (typ.)
<-125 dBm,
<-128 dBm (typ.)
5 MHz to 3.2 GHz
<-130 dBm,
<-134 dBm (typ.)
<-130 dBm,
<-134 dBm (typ.)
3.2 GHz to 6 GHz
<-126 dBm,
<-130 dBm (typ.)
6 GHz to 7.5 GHz
<-121 dBm,
<-125 dBm (typ.)
PA
on
100 kHz to 1 MHz <-142 dBm (typ.) <-142 dBm (typ.)
1 MHz to 5 MHz
<-142 dBm,
<-145 dBm (typ.)
<-142 dBm,
<-145 dBm (typ.)
5 MHz to 3.2 GHz
<-147 dBm,
<-151 dBm (typ.)
<-147 dBm,
<-151 dBm (typ.)
3.2 GHz to 6 GHz
<-143 dBm,
<-147 dBm (typ.)
6 GHz to 7.5 GHz
<-138 dBm,
<-142 dBm (typ.)
Displayed Average Noise Level (DANL)
DSA832E
Frequency
attenuation = 0 dB, RBW = VBW = 10 Hz, sample
detector, trace average ≥ 50, tracking generator off,
20℃ to 30℃, input impendence = 50 Ω
PA off
9 kHz to 100 kHz <-110 dBm (typ.)
100 kHz to 5 MHz <-122 dBm, <-128 dBm (typ.)
5 MHz to 3.2 GHz <-127 dBm, <-134 dBm (typ.)
PA on
100 kHz to 1 MHz <-142 dBm (typ.)
1 MHz to 5 MHz <-140 dBm, <-145 dBm (typ.)
5 MHz to 3.2 GHz <-145 dBm, <-151 dBm (typ.)
