Rigol DSA815 User Manual

RIGOL Chapter 2 Front Panel Operation
User’s Guide for DSA800/E Series
2-118
2. Reference level
The reference level, input attenuation, preamplifier and maximum mixing
level maintain coupling relationships. Refer to the introduction of equation
(2-3) in “Ref Level” for more details.
3. Input Attenuation
The input attenuation, reference level, preamplifier and maximum mixing
level maintain coupling relationships. Refer to the introduction of equation
(2-3) in “Ref Level” for more details.
4. RBW
This parameter maintains a coupling relationship with the span. Refer to “RBW”
for more details.
5. VBW
This parameter maintains a coupling relationship with RBW. Refer to “VBW”
for more details.
6. Sweep Time
The sweep time, RBW, VBW and span maintain coupling relationships. Refer
to “BW/Det” for more details.
Information
View the system information or messages recently shown on the screen.
1. System Information
 Model
 Serial Number
 Version of Main Board
 Version of Radio Frequency Board FPGA
 Version of Digital Board FPGA
 Version of TG Board FPGA (only for DSA815-TG/DSA832-TG/
DSA875-TG/DSA832E-TG)
 Version of Firmware
 Version of Boot

Rigol DSA815 Specifications

General

Frequency Range	9 kHz to 1.5 GHz
Input Impedance	50 Ω
Input Connector	N-type female
Weight	4.25 kg
Power Supply	100-240 V AC, 50/60 Hz
Phase Noise	-80 dBc/Hz @ 10 kHz offset
Amplitude Accuracy	±1.5 dB
Display	8 inch LCD (800x480 pixels)
Video Bandwidth (VBW)	1 Hz to 3 MHz
Maximum Input Level	+20 dBm
Interfaces	USB, LAN
Resolution Bandwidth (RBW)	100 Hz to 1 MHz
Dimensions	361 mm x 178 mm x 128 mm
