Rigol DSA815 User Manual

Chapter 2 Front Panel Operation RIGOL
User’s Guide for DSA800/E Series
2-103
Preset
Recall the preset setting and restore the analyzer to a specified status.
Key Points:
 Press System  Reset  Preset Type to select “Factory” or one of “User1”
to “User6”.
 Press Preset to load the factory settings listed in the following table (except
items marked with “**”) or User-defined settings.
Table 2-62 Factory Settings
Parameter Default
Frequency
Center Freq 3.75 GHz
Start Freq 0 Hz
Stop Freq 7.5 GHz
CF Step Auto, 750 MHz
Signal Track Off
Span
Span 7.5 GHz
Amplitude
Ref Level 0 dBm
Ref Offset 0 dB
Scale/Div 10 dB
Input Atten Auto, 10 dB
Scale Type Log
Units dBm
RF Preamp Off
Input 50 Ω
MaxMixL -10 dBm
Corrections Off
BW/Det
BW
RBW Auto, 1 MHz
VBW Auto, 1 MHz

Rigol DSA815 Specifications

General

Frequency Range	9 kHz to 1.5 GHz
Input Impedance	50 Ω
Input Connector	N-type female
Weight	4.25 kg
Power Supply	100-240 V AC, 50/60 Hz
Phase Noise	-80 dBc/Hz @ 10 kHz offset
Amplitude Accuracy	±1.5 dB
Display	8 inch LCD (800x480 pixels)
Video Bandwidth (VBW)	1 Hz to 3 MHz
Maximum Input Level	+20 dBm
Interfaces	USB, LAN
Resolution Bandwidth (RBW)	100 Hz to 1 MHz
Dimensions	361 mm x 178 mm x 128 mm
