Rigol DSA815 User Manual

RIGOL Chapter 2 Front Panel Operation
User’s Guide for DSA800/E Series
2-104
V/R Ratio 1
Detector
Det Type Pos Peak
Filter Type Gauss
Sweep/Trig
Sweep
Time Auto, 37.5 ms
Auto SWT Normal
Mode Cont
Numbers 1
Trig
Trig Type Free Run
Trig Level 0 dBm
Edge Positive
Trace/P/F
Trace
Select Trace 1
Trace Type of Trace 1 Clear Write
Avg Times 100
Function A-B
A T1
B T2
Const 0 dB
Operate Off
P/F
Switch Off
Meas Mode Cont
Limit Upper
Test Off
X-axis Freq
Freq Interp Lin
Fail Stop On
Beeper Off
Rel Freq Off
Rel Ampt Off
TG***

Rigol DSA815 Specifications

General

Frequency Range	9 kHz to 1.5 GHz
Input Impedance	50 Ω
Input Connector	N-type female
Weight	4.25 kg
Power Supply	100-240 V AC, 50/60 Hz
Phase Noise	-80 dBc/Hz @ 10 kHz offset
Amplitude Accuracy	±1.5 dB
Display	8 inch LCD (800x480 pixels)
Video Bandwidth (VBW)	1 Hz to 3 MHz
Maximum Input Level	+20 dBm
Interfaces	USB, LAN
Resolution Bandwidth (RBW)	100 Hz to 1 MHz
Dimensions	361 mm x 178 mm x 128 mm
