Chapter 6 Appendix
Appendix A: Ordering Infomation
Description
Order
Number
Model
spectrum analyzer, 9 kHz to 1.5 GHz
DSA815
spectrum analyzer, 9 kHz to 3.2 GHz
DSA832
spectrum analyzer, 9 kHz to 7.5 GHz DSA875
spectrum analyzer, 9 kHz to 3.2 GHz
DSA832E
spectrum analyzer, 9 kHz to 1.5 GHz
(with tracking
generator, factory installed)
DSA815-TG
spectrum analyzer, 9 kHz to 3.2 GHz (with tracking
generator, factory installed)
DSA832-TG
spectrum analyzer, 9 kHz to 7.5 GHz (with tracking
generator, factory installed)
DSA875-TG
spectrum analyzer, 9 kHz to 3.2 GHz (with tracking
generator, factory installed)
DSA832E-TG
Standard
accessories
quick guide (hard copy)
-
power cable -
Options
EMI filter & quasi-peak detector
EMI-DSA800
advanced measurement kit
AMK-DSA800
VSWR measurement kit
VSWR-DSA800
DSA PC software
Ultra Spectrum
signal seamless capture (Only for DSA815)
SSC-DSA
Optional
accessories
include: N-SMA cable, BNC-BNC cable, N-BNC
adaptor, N-SMA adaptor, 75 Ω to 50 Ω adaptor,
900 MHz/1.8 GHz antenna (2pcs), 2.4 GHz
antenna (2pcs)
DSA Utility Kit
include: N(F)-N(F) adaptor (1pcs), N(M)-N(M)
adaptor (1pcs), N(M)-SMA(F) adaptor (2pcs),
N(M)-BNC(F) adaptor (2pcs), SMA(F)-SMA(F)
adaptor (1pcs), SMA(M)-SMA(M) adaptor (1pcs),
BNC T type adaptor (1pcs), 50 Ω SMA load (1pcs),
50 Ω BNC impedance adaptor (1pcs)
RF Adaptor Kit
include: 50 Ω to 75 Ω adaptor (2pcs)
RF CATV Kit
include: 6dB attenuator (1pcs), 10dB attenuator
(2pcs)
RF Attenuator
Kit
30dB high power attenuator, max. power 100W
ATT03301H
N(M)-N(M) RF cable
CB-NM-NM-75-L
