Rigol DSA815 User Manual

RIGOL Chapter 3 Remote Control
User’s Guide for DSA800/E Series
3-2
Remote Control Overview
DSA800/E supports communication with PC via USB, LAN or GPIB (option)
interface for remote control. The remote control is realized on the basis of SCPI
(Standard Commands for Programmable Instruments) command set. DSA800/E
supports SCPI 1999.1 version.
When the instrument is in remote mode, the
icon is displayed in the user
interface and the front panel keys (except Esc) are locked. At this point, you can
press Esc to exist the remote mode.

Rigol DSA815 Specifications

General

Frequency Range	9 kHz to 1.5 GHz
Input Impedance	50 Ω
Input Connector	N-type female
Weight	4.25 kg
Power Supply	100-240 V AC, 50/60 Hz
Phase Noise	-80 dBc/Hz @ 10 kHz offset
Amplitude Accuracy	±1.5 dB
Display	8 inch LCD (800x480 pixels)
Video Bandwidth (VBW)	1 Hz to 3 MHz
Maximum Input Level	+20 dBm
Interfaces	USB, LAN
Resolution Bandwidth (RBW)	100 Hz to 1 MHz
Dimensions	361 mm x 178 mm x 128 mm
