Chapter 2 Front Panel Operation RIGOL

User’s Guide for DSA800/E Series

2-85

Select Mkr

Select one of the four markers and the default is Marker1. When a marker is

selected, you can set its type, trace to be marked, readout type and other related

parameters. The enabled marker will appear on the trace selected through the

Mkr Trace option and the readouts of this marker are also displayed in the active

function area and at the upper right corner of the screen.

Table 2-57 Marker parameters

Parameter

Explanation

Default

3.75 GHz

Range 0 to 7.5 GHz

Unit Readout = Frequency (or Period), units available are

GHz, MHz, kHz, Hz (or ks, s, ms, us, ns, ps);

Readout = Time (or 1/Δtime), units available are ks, s,

ms, us, ns, ps (or GHz, MHz, kHz, Hz)

Knob Step Readout = Frequency (or Period), step = Span/(Sweep

Points -1);

Readout = Time (or 1/Δtime), step = Sweep

Time/(Sweep Points -1)

Direction Key Step

Readout = Frequency (or Period), step = Span/10;

Readout = Time (or 1/Δtime), step = Sweep Time/10

Normal

One of the marker types. It is used to measure the X (Frequency or Time) and Y

(Amplitude) values of a certain point on the trace. When selected, a marker with

the number of the current marker (such as “1”) appears on the trace.

Key Points:

 If no active marker exists currently, a marker will be enabled automatically at

the center frequency of the current trace.

 You can use the numeric keys, knob or direction keys to move the marker. The

readouts of the marker will be displayed at the upper right corner of the

screen.
