Rigol DSA815 User Manual

Chapter 2 Front Panel Operation RIGOL
User’s Guide for DSA800/E Series
2-127
File Type
Press Storage  File Type to select the desired file type. The file types available
include All, Setup, State, Trace, Corrections, Measure, Marker Table, Peak Table
and Limit. The default is All. For the details about each type of file, see the table
below.
Note:
1) The State file only stores all the settings which are affected by pressing
Preset (see Table 2-62
). The Setup file not only stores all the settings which
are affected by pressing Preset but also stores the amplitude correction list
(the frequencies and amplitudes of the points to be corrected), the current
trace data (up to four traces) and the marker information (the readout type,
readings and the display status of the markers).
2) Measure, Marker Table and Peak Table in File Type are only available when
the corresponding functions are enabled.
3) When no external memory is connected, the various types of files will be
saved in BIN format by default.
Table 2-68 File type*
File Type Format Extension
Setup BIN .set
State BIN .sta
Trace
BIN .trc
CSV .csv
Amplitude
correction
BIN .cbl
CSV .csv
Measurement data CSV .csv
Marker table BIN .mkr
CSV .csv
Peak table CSV .csv
Limit BIN .lim
Note: *Mobile Disk (E:) supports all types of files; User Preset (C:) only supports “State” files
and Local (D:) supports all types of files except “Measure”, “Marker Table” and “Peak Table”.

Rigol DSA815 Specifications

General

Frequency Range	9 kHz to 1.5 GHz
Input Impedance	50 Ω
Input Connector	N-type female
Weight	4.25 kg
Power Supply	100-240 V AC, 50/60 Hz
Phase Noise	-80 dBc/Hz @ 10 kHz offset
Amplitude Accuracy	±1.5 dB
Display	8 inch LCD (800x480 pixels)
Video Bandwidth (VBW)	1 Hz to 3 MHz
Maximum Input Level	+20 dBm
Interfaces	USB, LAN
Resolution Bandwidth (RBW)	100 Hz to 1 MHz
Dimensions	361 mm x 178 mm x 128 mm
