Chapter 2 Front Panel Operation RIGOL

User’s Guide for DSA800/E Series

2-39

 X Axis: set the X-axis unit to frequency or time unit. Note that all the

points of the current limit line will be deleted when the X-axis unit

changes.

 Freq Interp: set the Freq Interp to Log or Lin. In Log mode, both the

frequency and amplitude use Log unit to make interpolation operation; in

Lin mode, the frequency uses a Lin unit and the amplitude uses a Log unit

for interpolation operation.

 Rel Setting: enable or disable Relative Frequency (Rel Freq) or Relative

Amplitude (Rel Ampt). When the Rel Freq is enabled, the frequency you

are editing is the difference between the frequency of the current point

and the center frequency. When the Rel Ampt is enabled, the amplitude

you are editing is the difference between the amplitude of the current

point and the reference level.

 Del Limit: delete the limit line you are editing.

 Fail Stop: select whether to perform the next sweep if the test fails.

 Beeper: turn on or off the beeper. When the beeper is on, it beeps when

the test fails.

3. Restart

Re-execute the active or suspended test.

4. Pause

Suspend the test after the current test is finished. At this point, the

measurement data stops updating, but the sweep continues.

is displayed

in the test result display window.

5. Resume

Resume the suspended test and the test data begins updating again.

displayed in the test result display window.

6. Meas Mode

Set the measurement mode to single or continuous. In single mode, the

analyzer stops after the specified number of tests. After this, every time when

Single is pressed, the system executes the specified number of tests and

updates the test data. In continuous mode, the analyzer tests continuously.
