Chapter 2 Front Panel Operation RIGOL

User’s Guide for DSA800/E Series

2-41

Set the parameter related to the tracking generator (TG). The tracking generator

provides two working modes: Power Sweep output (when Power Sweep is On) and

Fixed Power output (when Power Sweep is Off). The TG function is only valid when

your analyzer is DSA815-TG/DSA832-TG/DSA875-TG/DSA832E-TG.

TG is used to enable or disable the TG.

When the TG is enabled, a signal with the same frequency of the current sweep

signal will be output from the [GEN OUTPUT 50Ω] connector at the front panel.

The power of the signal could be set through the menu. The tracking generator

provides two working modes: Power Sweep output (when Power Sweep is On) and

Fixed Power output (when Power Sweep is Off).

TG Level

Set the output power of the signal of the tracking generator. In Power Sweep mode,

this parameter indicates the start power of the sweep.

You can use the numeric keys, knob or direction keys to modify this parameter. For

more details, please refer to “Parameter Setting”.

Table 2-23 TG level

Parameter Explanation

Default -20 dBm

Range* -40 dBm to 0 dBm

Unit dBm, -dBm, mV, uV

Knob Step 1 dBm

Direction Key Step 10 dBm

Note: *The minimum TG Level for DSA815-TG is -20 dBm.
