12
Preparations
S u f f i c i e n t r e m a i n i n g
c a p a c i t y
B a t t e r i e s
l o w
F l a s h i n g
R e p l a c e b a t t e r i e s
Battery life
Alkaline batteries LR14 approx. 20 hours
Manganese batteries R14P approx. 9 hours
* The above values were determined under the following conditions.
20°C 50% RH, accelerometer PV-85, ACC, HPF OFF, LPF OFF, back-
light OFF, switch LEDs OFF, communications OFF (MENU 0-0), con-
tinuous operation
* The actual battery life will differ, depending on the accelerometer, set-
tings, ambient conditions, and battery type.
When the backlight is used, battery consumption will be about 20% higher.
When the servo accelerometer is connected, current consumption increases by
about 15%.
Remaining battery capacity indication
The following indication appears on the display, depending on the battery sta-
tus.
Note
When the battery indicator start to flash, replace the
batteries immediately. While the indicator is flash-
ing, the measurement will not be accurate.
AC Adapter
The unit can be powered from the following adapter: NC-98 (option)
Connect the cable from the AC adapter to the external power supply connector
on the rear panel.
