Technical Information
8 0
7 0 7 8 . 56 1 . 5
4 - M 3
F r o n t
U n i t : m m
V M - 8 3 b o t t o m
Group Delay
The VM-83 directly converts the vibration input signal from analog into digital
form and performs signal processing in the digital domain, using a DSP. The
signal is then reconverted to analog for the AC and DC output. For this reason,
a certain delay (group delay) is introduced as shown below.
Rack Mounting
The VM-83 can be mounted in a rack, using the four screw holes on the bottom
of the unit.
V i b r a t i o n i n p u t s i g n a l
A C o u t p u t s i g n a l
a p p r o x . 6 0 0 µ s

Rion VM-83 Specifications

General

Brand	Rion
Model	VM-83
Category	Measuring Instruments
Language	English
