Rish Master 3430 User Manual

Address Parameter Description
40049
Pulse 1
parameter
select
40045
PT secondary This address is used to read and write the PT secondary value.
The valid range for PT Secondary is 100 VLL to 600 VLL.
This address is used to assign the Parameter to Relay1
refer table 7.
40043
CT secondary
This address is used to read and write the CT secondary value
write one of the following values to this address.
1=1A CT secondary
5=5A CT secondary
writing any other value will return an error.
40061
Pulse 2
Parameter
This address is used to assign the Parameter to Relay2
refer table 7.
40071
Password
This address is used to set & reset the password.
Valid Range of Password can be set is 0000 - 9999 .
1) If password lock is present & if this location is read it will
return zero.
2) If Password lock is absent & if this location is read it will
return One.
3) If password lock is present & to disable this lock
first send valid password to this location then write “0000”
to this location
4) If password lock is present & to modify 4X parameter
rst send valid password to this location so that 4X parameter
will be accessible for modication.
5) If for in any of the above case invalid password is send then
meter will return exceptional error 2.
Select
56
