GD-70D - 40 -
Mode (see pg.
67)
Perform the gas introduction test.
Perform the zero adjustment.
Perform the span adjustment.
Show the last calibrated date.
Bias Voltage (Element
2-4 BIAS
Show the bias voltage.
(Show the element voltage.)
Flow Rate Setting
(adjusted to 0.5 L/min)
Set the flow sensor with the flow rate at 0.5 L/min.
Pump Ratio/Flow Rate
2-6 FLOW Show the output and flow rate of the current pump.
Show the current temperature of the installation environment.
Suggested Warm-up
2-8 WARMTIME Show the suggested warm-up completion for semiconductor type
• INHIBIT setting (INHIBIT)
•
Alarm value setting (ALM P)
•
Alarm delay time setting (ALM DLY)
•
Regular replacement operation (pump stop) (MAINTE)
•
Environmental Setting 2 2-10 SETTING2 Function settings
•
Address setting (ADDRESS)
•
Date/Time setting (DAY TIME)
•
Zero suppression value setting (SUPPRESS)
•
Zero suppression system setting (SUP TYPE)
•
Alarm test time contact setting (TEST RLY)
•
Alarm test time external output setting (TEST4-20)
•
Energized/De-energized setting (RLY PTRN)
•
Alarm type setting (ALM TYP)
•
Alarm activation setting (ALM PTRN)
•
Alarm value limiter setting (AL LIMIT)
•
Fault activation setting (FLT PTRN)
•
Flow rate auto-adjustment setting (AT FLOW)
•
Zero follower ON/OFF setting (ZERO F)
•
24 hours zero follower ON/OFF setting (ZERO 24F)
•
Sensitivity correction ON/OFF setting (S ASSIST)
•
External output in maintenance mode setting (MNT OUT)
•
External output adjustment (MA 4-20)
•
Backlight setting (BK LIGHT)
•
ETHERNET setting (ETHERNET)
• Pump drive level diagnosis ON/OFF setting (PUMP CK)
If a pyrolyzer unit is being used, this menu displays data for it (see
the PLU-70 operator’s manual for more description)
