Maintenance Mode
PW
A1
A2
F
LCD
From Detection Mode, press
and hold the MODE key for
three seconds.
●
○
○
○
0.0ppm
SIH4
↓
↓
1-8.M MODE
Press the ▲ key until the
Maintenance Mode screen
displays. (For GD-70D-EA
units, the Maintenance Mode
screen is item 1-9.)
●
○
○
○
1- 8
M MODE
MAINTENANCE
↓
↓
User Mode
In "1-8.M MODE", press the
SET key.
●
○
○
○
1- 8
M MODE
MAINTENANCE
↓
↓
Then press and hold the SET
key again for three seconds.
●
○
○
○
- - - -
M MODE
MAINTENANCE
↓
Maintenance Mode
↓
2-0.GAS TEST
Perform a test with the gas.
The reading changes and the
alarm lamp lights up, but the
alarm contacts are not
activated and the 4-20 mA
output does not track the
changes.
●
○
○
○
2- 0
GAS TEST
MAINTENANCE
→
SET
0.2ppm
GAS TEST
MAINTENANCE
▲↓ ↑▼
↓
(Alternate Display)
↑
0.2ppm
SIH4
MAINTENANCE
2-1.ZERO
Perform a zero adjustment.
●
○
○
○
2- 1
ZERO
MAINTENANCE
→
SET
Zero Adjustment
⇒P86
▲
↓ ↑
▼
2-2.SPAN
Perform a span adjustment.
●
○
○
○
2- 2
SPAN
MAINTENANCE
→
SET
Span Adjustment
⇒P86
▲
↓ ↑
▼
PW: POWER
A1: ALM1
A2: ALM2
F: FAULT
●: Lamp on
○: Lamp off
