GD-70D - 66 -
Maintenance Mode Item
LCD Display
Details
Environmental Setting 2
⇒P74
2-10 SETTING2
Function settings
• Address setting (ADDRESS)
• Date/Time setting (DAY TIME) ⇒P79
• Zero suppression value setting (SUPPRESS)
• Zero suppression type setting (SUP TYPE)
• Alarm test mode contact setting (TEST RLY)
• Alarm test mode external output setting (TEST4-20)
• Energized/De-energized setting (RLY PTRN)
⇒P81
• Alarm type setting (ALM TYP)
• Alarm activation setting (ALM PTRN)
• Alarm value limiter setting (AL LIMIT)
• Fault activation setting (FLT PTRN)
• Flow rate auto-adjustment setting (AT FLOW)
• Zero follower ON/OFF setting (ZERO F)
• 24 hours zero follower ON/OFF setting (ZERO 24F)
• Sensitivity correction ON/OFF setting (S ASSIST)
• External output in maintenance mode setting (MNT OUT)
• External output adjustment (MA 4-20)
• Backlight setting (BK LIGHT)
• ETHERNET setting (ETHERNET)
• Pump drive level diagnosis ON/OFF setting (PUMP CK)
Pyrolyzer Data Display
2-11 PL DATA
When the pyrolyzer unit (PLU-70) is used, a variety of
pyrolyzer data is displayed.
(See the operating manual for PLU-70)
Fault Investigation
2-12 FAULT
Not used
Factory Mode Switching
2-13 F MODE
Not used
