GD-70D - 60 -
1-5.70D VER
Show the program version
of the main unit.
●
○
○
○
1- 5
70D VER
MAINTENANCE
→
SET
01234
56AB
MAINTENANCE
▲
↓ ↑
▼
1-6.UNIT VER
Show the program version
of the installed sensor unit.
●
○
○
○
1- 6
UNIT VER
MAINTENANCE
→
SET
01234
56AB
MAINTENANCE
▲
↓ ↑
▼
1-7.NET VER
Show the program version
of the communication
function.
(for GD-70D-NT)
●
○
○
○
1- 7
NET VER
MAINTENANCE
→
SET
01234
----
MAINTENANCE
▲
↓ ↑
▼
1-8.M MODE
Enter Maintenance Mode.
●
○
○
○
1- 8
M MODE
MAINTENANCE
→
SET
See Maintenance
Mode on page 65.
▲
↓ ↑
▼
To 1-1.ZERO
【
In case of GD-70D-EA
】
1-7. NET VER
Show the program
version of the
communication
function.
(NT specification)
●
○
○
○
1- 7
NET VER
MAINTENANCE
→
SET
01234
----
MAINTENANCE
▲
↓↑
▼
1-8.COM SET
Set communication
output.
Press the ▲ or ▼ key
to select the
communication
output, and then press
the SET key to
confirm the value.
●
○
○
○
1- 8
COM SET
MAINTENANCE
⇔
SET
A
COM SET
MAINTENANCE
▲
↓↑
▼
｜↑
｜｜
▲｜｜▼
A: Analog transmission
E: Ethernet
EA: Ethernet and analog
transmission
E
COM SET
MAINTENANCE
▲↓↑▼
EA
COM SET
MAINTENANCE
