RKI Instruments GD-70D Series User Manual

- 75 - GD-70D
2-0.GAS TEST
The first item in Maintenance
Mode will display.
●
○
○
○
2- 0
GAS TEST
MAINTENANCE
↓
↓
2-10. SETTING2
Press the ▲ key until the
SETTING2 screen displays.
Press the SET key.
●
○
○
○
2- 10
SETTING2
MAINTENANCE
↓
↓
SET 0. ADDRESS
Set the address for GD-70D-
NT units.
Select the number by
pressing the ▲ or ▼ key,
and then press the SET key
to confirm the address.
●
○
○
○
SET 0
ADDRESS
MAINTENANCE
⇔
SET
01
ADDRESS
MAINTENANCE
▲
↓ ↑
▼
SET 1.DAY TIME
Set the date/time of the main
unit.
●
○
○
○
SET 1
DAY TIME
MAINTENANCE
⇔
SET
Date/Time Setting
⇒P79
▲
↓ ↑
▼
SET 2.SUPPRESS
Set the suppression value.
Select the number by
pressing the ▲ or ▼ key,
and then press the SET key
to confirm the value.
●
○
○
○
SET 2
SUPPRESS
MAINTENANCE
⇔
SET
0.9ppm
SUPPRESS
MAINTENANCE
▲
↓ ↑
▼
SET 3. SUP TYPE
Set the suppression system.
Select either CUT or SLOPE,
and then press the SET key
to confirm the selection.
When CUT is selected, the
display will jump up to the
gas reading as soon as it
exceeds the suppression
value. When SLOPE is
selected, the display will
ramp up to the gas reading
once it exceeds the
suppression value.
●
○
○
○
SET 3
SUP TYPE
MAINTENANCE
⇔
SET
CUT
SUP TYPE
MAINTENANCE
▲↓ ↑▼
▲
↓↑
▼
SLOPE
SUP TYPE
MAINTENANCE
SET 4. TEST RLY
Set the contact activation for
an alarm test.
Select either ON or OFF, and
then press the SET key to
confirm the selection.
When ON is selected, the
contact can be activated
even during an alarm test.
●
○
○
○
SET 4
TEST RLY
MAINTENANCE
⇔
SET
OFF
TEST RLY
MAINTENANCE
▲
↓ ↑▼
▲
↓↑
▼
ON
TEST RLY
MAINTENANCE
