Performing a Span Adjustment
2-2. SPAN
Press the ▲ key until the SPAN screen
displays.
Press the SET key.
2- 2
SPAN
MAINTENANCE
Connect Gas
Use the calibration tubing to connect the
demand flow regulator to the tubing stub on
the GAS IN fitting. Gas will begin to flow.
Allow gas to flow for 2 minutes.
↓
↓
Accept Reading
Press the SET key when the reading has
stabilized.
* The reading must be above 10% of the full
scale value in order to continue.
2.0ppm
SPAN GAS
MAINTENANCE
Disconnect Gas
Disconnect the calibration tubing from the
tubing stub on the GAS IN fitting.
↓
↓
Span Adjustment
Using the ▲ or ▼ keys, adjust the reading to
match the concentration listed on your
calibration cylinder.
Press the SET key.
8.0ppm
SPAN VAL
MAINTENANCE
↓
↓
Span Adjustment Completed
The instrument will indicate whether the span
adjustment passed (OK) or failed (NG).
8.0ppm
SPAN OK
MAINTENANCE
OR
8.0ppm
SPAN NG
MAINTENANCE
↓
↓
↓
Return to 2-2.SPAN
Save Adjustment
To save the adjustment result, press the SET
key.
(Press the MODE key to cancel this menu.)
8.0ppm
SPAN Y/N
MAINTENANCE
↓
↓
Adjustment Completed
After the span has been recorded, the
instrument will return to 2-2.SPAN
automatically.
8.0ppm
SPAN END
MAINTENANCE
