18 • Standard Accessories GX-2003 Operator’s Manual
Standard Accessories
The standard accessories include the tapered rubber nozzle, protective
rubber boot, sample hose, and 10 inch probe. An optional bar hole
probe is also available and is described at the end of this section.
Tapered Rubber Nozzle
A cone shaped 4 inch long rubber nozzle is included with the GX-2003
as standard. It can be installed on the inlet fitting by pushing the
larger end over it. The smaller end can be inserted through a hole in a
wall or some other access to an enclosed area to sample the
environment.
Protective Rubber Boot
A protective rubber boot is provided as standard with the GX-2003. It
has an integral belt clip on the back. The boot can be installed onto the
GX-2003 for additional protection and to wear the GX-2003 on a belt.
Figure 3: Protective Rubber Boot
Belt Clip
