GX-2003 Operator’s Manual Replacing a Sensor 81
Figure 10: Replacing a Sensor
HC
VOL
HC
LEL
CO
H2S
O2
Exhaust
% Volume
Combustib
le
Sensor
% LEL
Combustib
le
Sensor
CO Senso
r
H2S
Sensor
Oxygen
Sensor
Align Slots in H2S
and CO Sensors With
Tabs in Sockets
Flow Chamber
