41
Frost 2/1 channel 82 channel 84
Frost 2/2 channel 83 channel 85
Fr. Shutters rot. channel 84 channel 86
Fr. Shutter 1 Move channel 85 channel 87
Fr. Shutter 1 swiveling. channel 86 channel 88
Fr. Shutter 2 Move channel 87 channel 89
Fr. Shutter 2 swiveling channel 88 channel 90
Fr. Shutter 3 Move channel 89 channel 91
Fr. Shutter 3 swiveling channel 90 channel 92
Fr. Shutter 4 Move channel 91 channel 93
Fr. Shutter 4 swiveling channel 92 channel 94
Calibrate Fr. Hysteresis
Framing Lamella 1 - a framing lamella 1 reverse movement (value range: 0-8)
Framing Lamella 2 - a framing lamella 2 reverse movement (value range: 0-8)
Framing Lamella 3 - a framing lamella 3 reverse movement (value range: 0-8)
Framing Lamella 4 - a framing lamella 4 reverse movement (value range: 0-8)
The value set for every framing lamella gives a value at which the lamella reacts to its reverse
movement promptly (without movement hysteresis).
Calibrate Pan/Tilt EMS - The menu item allows calibration of the pan/tilt electronic motion stabilizer.
Important: during this calibration any external force must not inuence the xture and the surface at which
the xture stands (or truss if the xture hangs) has to be without movement, shake, strokes etc.
Calibrate Pan/Tilt Reset - The menu item is used for calibration of pan/tilt reset in factory and also has to
be used in case of changing of pan or tilt motor or pan/tilt control PCB (RB3138 in the xture yoke).
Load Default Calibrations - The item loads default (factory) calibration values.
Rotating Gobos Change - This menu makes changing of rotating gobos in the xture easier.
Gobo Carousel 1 - The menu allows movement of rotating gobos on the gobo carousel 1 to positions suitable
for their changing.
G1-Mg - a movement of the gobo 1 (gobo holder with magnet) to the changing position.
G2 - a movement of the gobo 2 to the changing position.
:
Gobo O󰀨set -a gobo o󰀨set setting. The function allows ne swivelling of the gobo holder. The set value
is valid for all gobos on the gobo carousel 1.
Gobo Carousel 2 - The menu allows movement of rotating gobos on the gobo carousel 2 to positions suitable
for their changing.
G1-Mg - a movement of the gobo 1 (gobo holder with magnet) to the changing position.
G2 - a movement of the gobo 2 to the changing position.
:
Gobo O󰀨set -a gobo o󰀨set setting. The function allows ne swivelling of the gobo holder. The set value
is valid for all gobos on the gobo carousel 2.
LEDs Measure - This menu item runs a procedure which measures a light intensity of the LEDs module installed
in the xture. This procedure takes about 1 minute (message " LEDs Module Measurement" is displayed on
the screen"). During the procedure the xture does not receive DMX signal, pan/tilt go to 128 DMX, a shutter
is open and a dimmer is set at max. light intensity (255 DMX). All e󰀨ects are taken out from the light beam.
The measured light intensity is recorded in the item Intensity in the menu LED Module Info:
Tab Information --> Actual Module Info --> Intensity
Tab Information --> Intensity History --> Intensity
The light intensity in the menu item Intensity is displayed in percentages in relation to the initial intensity of the
new LEDs module (initial intensity=100%).
The LEDs Measure procedure should be run after every change of the LED light source.
Note: The xture has to be connected to mains in order to run LEDs Measure procedure.
Update software - The menu item allows you to update software in the xture.
The following items are required in order to update software:
- PC running Windows or Linux or macOS
- DSU le
- Flash cable RS232/DMX, P/N13050624 (if you want to use a serial port of PC)
