DMX protocol
1 2
Mode/Channel
DMX
Value
Function
Type of
control
7 7
LED frequency selection
Factory display menu setting: 600Hz
Select PWM output frequency of LEDs. Selected PWM frequency can be
fine adjusted in 127 steps up/down around selected PWM frequency on
the channel below. Corresponding menu item (Frequency Setup) is
temporarily overridden.
0-4
PWM frequency from Display menu (fixture utilizes PWM
step
frequency set in the display menu item Frequency Setup).
5-9 300 Hz step
10-14 600 Hz (10=default) step
15-19 1200 Hz step
20-24 2400 Hz step
25-255
Reserved (fixture utilizes PWM frequency set in the display menu item
Frequency Setup).
8 8
LED frequency fine adjusting
Factory display menu setting: 600Hz
Select desired PWM output frequency of LEDs on the channel above.
0-1 Selected LED Frequency step
2 LED Frequency (step -126) step
3 LED Frequency (step -125) step
4 LED Frequency (step -124) step
:
125 LED Frequency (step -3) step
126 LED Frequency (step -2) step
127 LED Frequency (step -1) step
128
Selected LED Frequency (128=default)
step
129 LED Frequency (step +1) step
130 LED Frequency (step +2) step
131 LED Frequency (step +3) step
:
252 LED Frequency (step +124) step
253 LED Frequency (step +125) step
254 LED Frequency (step +126) step
255 Selected LED Frequency step
9 9 Max. light intensity indication and setting
0-10 No function (0=default)
11-20 Indication of drop of max. light intensity step
A drop of max. light intensity of the fixture (compared to its
original intensity) is indicated by a corresponding colour output:
0-5%, (WHITE /new LED module/)
6-10% (RED)
11-15% (GREEN)
16-20% (BLUE )
21-25% (CYAN )
26-30% (MAGENTA)
31-35% (YELLOW)
36-40% (ORANGE)
Pan/tilt/zoom is set at 128 DMX (50%), Dimmer is open at 255
DMX (100%).
