Robe iForte - Page 84

DMX protocol
1 2
Mode/Channel
DMX
Value
Function
Type of
control
To set a drop of max. light intensity (compared to original light
intensity), stay at DMX value for at least 3 sec. and shutter must
be closed at least 3 sec. (Channel „Shutter/ Strobe” 52/54 must be
at range: 0-31 DMX). Corresponding menu items are permanently
overwritten.
21-30 Set drop by 6-10% (RED) step
31-40 Set drop by 11-15% (GREEN) step
41-50 Set drop by 16-20% (BLUE) step
51-60 Set drop by 21-25% (CYAN) step
61-70 Set drop by 26-30% (MAGENTA) step
71-80 Set drop by 31-35% (YELLOW) step
81-90 Set drop by 36-40% (ORANGE) step
91-100 Original intensity (WHITE) step
101-255 Reserved
10 10
Colour wheel 1
Continual positioning
0 Open/white (0=default) proportional
21 Deep red proportional
43 Deep blue proportional
64 Orange proportional
86 Green proportional
107 Congo blue proportional
128-129 Open/White step
Positioning
130-141 Deep red step
142-153 Deep blue step
154-165 Orange step
166-177 Green step
178-189 Congo blue step
190 - 215 Forwards rainbow effect from fast to slow proportional
216 - 217 No rotation step
218 - 243 Backwards rainbow effect from slow to fast proportional
244 - 249 Reserved
250 - 255 Auto random colour selection from fast to slow proportional
11 11
Colour wheel 1 - fine positioning
0 - 255 Fine positioning (0=default) proportional
12 12
Colour wheel 2
Continual positioning
0 Open/white (0=default) proportional
21 Multicolour proportional
43 Laser green proportional
64 Lavender proportional
86 Filter CRI 80 proportional
107 Filter CRI 90 proportional
128-129 Open/White step
Positioning
130-141 Multicolour step
142-153 Laser green step
154-165 Lavender step
