DMX protocol
1 2
Mode/Channel
DMX
Value
Function
Type of
control
166-177 Filter CRI 80 step
178-189 Filter CRI 90 step
190 - 215 Forwards rainbow effect from fast to slow proportional
216 - 217 No rotation step
218 - 243 Backwards rainbow effect from slow to fast proportional
244 - 249 Reserved
250 - 255 Auto random colour selection from fast to slow proportional
13 13
Colour wheel 2 - fine positioning
0 - 255 Fine positioning (0=default) proportional
14 14
0 - 255 Cyan from min. saturation --> full cyan (0=default) proportional
15 15
0 - 255 Magenta from min. saturation --> full magenta (0=default) proportional
16 16
0 - 255 Yellow from min. saturation --> full yellow (0=default) proportional
17 17
0 - 255 CTO from 6700K --> 3000K (0=default) proportional
18 18 Green correction
0 Uncorrected white step
1-127 Minus green --> uncorrected white proportional
128 Uncorrected white (128=default) step
129-255 Uncorrected white --> Plus green proportional
19 19
See table "Colours on Virtual Colour Wheel" to find components
of each colour
The following channels are disabled: 9-18
0 No function (0=default) step
1-2
Filter 4 (Medium Bastard Amber)
step
3-4
Filter 10 (Medium Yellow)
step
5-6
Filter 19 (Fire)
step
7-8
Filter 26 (Bright Red)
step
9-10
Filter 58 (Lavender)
step
11-12
Filter 68 (Sky Blue)
step
13-14
Filter 71 (Tokyo Blue)
step
15-16
Filter 79 (Just Blue)
step
17-18
Filter 88 (Lime Green)
step
19-20
Filter 90 (Dark Yellow Green)
step
21-22
Filter 100 (Spring Yellow)
step
23-24
Filter 101 (Yellow)
step
25-26
Filter 102 (Light Amber)
step
27-28
Filter 103 (Straw)
step
29-30
Filter 104 (Deep Amber)
step
31-32
Filter 105 (Orange)
step
33-34
Filter 106 (Primary Red)
step
35-36
Filter 111 (Dark Pink)
step
37-38
Filter 115 (Peacock Blue)
step
39-40
Filter 116 (Medium Blue-Green)
step
41-42
Filter 117 (Steel Blue)
step
