DMX protocol
1 2
Mode/Channel
DMX
Value
Function
Type of
control
55-59 Gobo 6 step
Shaking gobos from slow to fast
Index - set indexing on channel 30
60-71 Gobo 1 proportional
72-83 Gobo 2 proportional
84-95 Gobo 3 proportional
96-106 Gobo 4 proportional
107-118 Gobo 5 proportional
119-129 Gobo 6 proportional
Shaking gobos from slow to fast
Rotation - set rotation on channel 30
130-141 Gobo 1 proportional
142-153 Gobo 2 proportional
154-165 Gobo 3 proportional
166-176 Gobo 4 proportional
177-188 Gobo 5 proportional
189-199 Gobo 6 proportional
200 - 201 Open/hole step
202 - 222 Forwards gobo wheel rotation from fast to slow proportional
223 - 243 Backwards gobo wheel rotation from slow to fast proportional
244 - 249 Reserved
250 - 255 Auto random gobo selection from fast to slow proportional
* 30
Rotating gobo wheel 2
Index - set indexing on channel 32
0-4 Open/hole (0=default) step
5-8 Gobo 1 step
9-13 Gobo 2 step
14-17 Gobo 3 step
18-22 Gobo 4 step
23-26 Gobo 5 step
27-31 Gobo 6 step
Rotation - set rotation on channel 32
32-35 Gobo 1 step
36-40 Gobo 2 step
41-44 Gobo 3 step
45-49 Gobo 4 step
50-54 Gobo 5 step
55-59 Gobo 6 step
Continual positioning
Index - set indexing on channel 32
60 Open/hole proportional
70 Gobo 1 proportional
80 Gobo 2 proportional
90 Gobo 3 proportional
100 Gobo 4 proportional
110 Gobo 5 proportional
120 Gobo 6 proportional
130 Open/hole proportional
