DMX protocol
1 2
Mode/Channel
DMX
Value
Function
Type of
control
Continual positioning
Rotation - set rotation on channel 32
131 Open/hole proportional
141 Gobo 1 proportional
151 Gobo 2 proportional
161 Gobo 3 proportional
171 Gobo 4 proportional
181 Gobo 5 proportional
191 Gobo 6 proportional
201 Open/hole proportional
202 - 222 Forwards gobo wheel rotation from fast to slow proportional
223 - 243 Backwards gobo wheel rotation from slow to fast proportional
244 - 249 Reserved
250 - 255 Auto random gobo selection from fast to slow proportional
* 31
Rotating gobo wheel 2 - fine positioning
0 - 255 Fine positioning (0=default) proportional
30 32
Rot. Gobo 2 indexing and rotation
Gobo indexing - set position on channel 29/30
0 - 255 Gobo indexing proportional
Gobo rotation - set position on channel 29/30
0 No rotation step
1 - 127 Forwards gobo rotation from fast to slow proportional
128 No rotation (128=default) step
129 - 255 Backwards gobo rotation from slow to fast proportional
31 33
Rot. Gobo 2 indexing/rotation - fine
0-255 Fine indexing/rotation (0=default) proportional
32 34
Prism 1 (6-facet linear)
0 - 19 Open position - hole (0=default) step
20 - 73 Prism 1 indexing step
74-127 Prism 1 rotation step
Prism 1 /gobo macros
The following channels are blocked: Prism 1, Prism 1 indexing/ rotation,
Rotating gobo 1/2 wheel, Rot. Gobo 1/2 indexing and rotation, Rot. Gobo
1/2 fine rotation.
128 - 135 Macro 1 step
136 - 143 Macro 2 step
144 - 151 Macro 3 step
152 - 159 Macro 4 step
160 - 167 Macro 5 step
168 - 175 Macro 6 step
176 - 183 Macro 7 step
184 - 191 Macro 8 step
192 - 199 Macro 9 step
200 - 207 Macro 10 step
208 - 215 Macro 11 step
216 - 223 Macro 12 step
224 - 231 Macro 13 step
232 - 239 Macro 14 step
