6. “Bubble wrap” spool carrying unit:
suitable for wrapping edges or sides, using bubble wrap spools or similar ones. It features film “quick loading”
and a safety device to stop the carriage.
- Template:
Profiled structure for base underground installation.
- Rotary table (ø 1800, ø 2200, ø 2400, ø 1800 “longer”):
it is used to wrap pallets with a size greater than the standard one.
- Brake shaft for mesh (only for “FRD” spool carriages):
it is used to obtain a correct tensioning of the mesh.
- Slide shaft (2400 - 2800 - 3100 mm):
it is used to wrap pallets which are higher than the standard ones.
- Automatic cutting device:
it automatically cuts the film at the end of the cycle.
(Only for machines “Rotoplat - Rotoplat TP3 508-708”).
7. Creasing device:
it is used during wrapping to gather the film in one point, providing the package with a reinforcement point.
8. Film reinforcement tool:
it is used to create a film reinforcement on the base of the product or on the pallet.
