Robustel GoRugged R2000 User Manual

Robustel GoRugged R2000 User Guide
RT_UG_R2000_v.1.2.0 15.12.2015 34 /120
Confidential
WLAN
WLAN Setting
Item
Description
Default
SSID
Enter SSID of the access point which R2000 want to connect.
Input from 1 to 32 characters.
router
Connect to Hidden SSID
When R2000 works as Client mode and need to connect to any access
point which has hidden SSID, you need to enable this feature.
OFF
Password
Enter access point’s passphrase which it wants to connect to.
Input from 8 to 63 characters.
Null
Debug Level
Select from “verbose”, “debug”, “info”, “notice”, “warning”, “none”.
None
When choose the WLAN Connection Type as DHCP, R2000 will obtain IP automatically from the WLAN AP.
When choose the WLAN Connection Type as Static. Please enter the related parameter in the Static Address Setting
window.
Static Address Setting
Item
Description
Default
IP Address
Enter the IP address which was identified by the WiFi AP.
IP address with netmask, e.g. 192.168.1.1/24
Null
Gateway
Enter the WiFi AP’s IP address.
Null

Robustel GoRugged R2000 Specifications

General

Model	GoRugged R2000
Category	Network Router
Ethernet Ports	2 x 10/100 Mbps
SIM Slots	2
Power Supply	9-36 VDC
USB Port	1 x USB 2.0
Cellular Connectivity	4G LTE, 3G
VPN Support	IPsec, OpenVPN, GRE
Operating Temperature	-40°C to +75°C
WiFi	802.11 b/g/n
Serial Interface	RS232/RS485
GPS	Yes
Firewall	SPI Firewall
Digital Input/Output	2 x DI
