Robustel GoRugged R2000 User Guide
RT_UG_R2000_v.1.2.0 15.12.2015 69 /120
Confidential
Select from “None”, “Preshared”, “Password”, “X509CA” and “X509CA
Password”. “None” and “Preshared” type just work with p2p mode.
When the “Mode” is “P2P”.
Define the local IP address of OpenVPN tunnel.
When the “Mode” is “P2P”.
Define the remote IP address of OpenVPN tunnel.
User name used for Authentication Type “Password” or “X509CA
Password”.
Password used for Authentication Type “Password” or “X509CA
Password”.
Select from “BF”, “DES”, “DES-EDE3”, “AES128”, “AES192” and
“AES256”.
BF: Uses the BF algorithm in CBC mode and 128-bit key.
DES: Uses the DES algorithm in CBC mode and 64-bit key.
DES-EDE3: Uses the 3DES algorithm in CBC mode and 192-bit key.
AES128: Uses the AES algorithm in CBC mode and 128-bit key.
AES192: Uses the AES algorithm in CBC mode and 192-bit key.
AES256: Uses the AES algorithm in CBC mode and 256-bit key.
Set keepalive (ping) interval to check if the tunnel is active.
Trigger OpenVPN restart after n seconds pass without reception of a
ping or other packet from remote.
Password of Private Key for Authentication Type “X509CA”
Enable to compress the data stream.
Tick to enable NAT for OpenVPN. The source IP address of host behind
R2000 will be disguised before accessing the remote OpenVPN client.
Select the level of the output log. Values range from 0 to 11.
0 -- No output except fatal errors.
1 to 4 -- Normal usage range.
5 -- Output R and W characters to the console for each packet read
and write.
6 to 11 -- Debug info range
