Robustel R2000 User Manual

Robustel R2000 User Guide
RT_UG_R2000_v.3.0.0 July 24, 2017 116 / 124
Confidential
# set link_manager primary_link wwan1 //select “wwan1” as primary_link
OK //setting succeed
# set link_manager link 1
type Type
desc Description
connection_type Connection Type
wwan WWAN Settings
static_addr Static Address Settings
pppoe PPPoE Settings
ping Ping Settings
mtu MTU
dns1_overrided Overrided Primary DNS
dns2_overrided Overrided Secondary DNS
# set link_manager link 1 type wwan1
OK
# set link_manager link 1 wwan
auto_apn Automatic APN Selection
apn APN
username Username
password Password
dialup_number Dialup Number
auth_type Authentication Type
aggressive_reset Aggressive Reset
switch_by_data_allowance Switch SIM By Data Allowance
data_allowance Data Allowance
billing_day Billing Day
# set link_manager link 1 wwan switch_by_data_allowance true
OK
#
# set link_manager link 1 wwan data_allowance 100 //open cellular switch_by_data_traffic
OK //setting succeed
# set link_manager link 1 wwan billing_day 1 //setting specifies the day of month for billing
OK // setting succeed
…
# config save_and_apply
OK // save and apply current configuration, make you configuration effect
Example 4: Set LAN IP address
# show lan all
network {
id = 1
interface = lan0
ip = 192.168.0.1
netmask = 255.255.255.0

Robustel R2000 Specifications

General

Model	R2000
Category	Network Router
Cellular Connectivity	4G LTE
WAN Ports	1
Ethernet Ports	2
Input Voltage	9-36 VDC
SIM Slots	2
Certifications	CE, FCC, RoHS
Operating Temperature	-40°C to 75°C
