Robustel R2000 User Manual

Robustel R2000 User Guide
RT_UG_R2000_v.3.0.0 July 24, 2017 117 / 124
Confidential
mtu = 1500
dhcp {
enable = true
mode = server
relay_server = ""
pool_start = 192.168.0.2
pool_end = 192.168.0.100
netmask = 255.255.255.0
gateway = ""
primary_dns = ""
secondary_dns = ""
wins_server = ""
lease_time = 120
expert_options = ""
debug_enable = false
}
}
multi_ip {
id = 1
interface = lan0
ip = 172.16.10.67
netmask = 255.255.0.0
}
#
# set lan
network Network Settings
multi_ip Multiple IP Address Settings
vlan VLAN
# set lan network 1(space+?)
interface Interface
ip IP Address
netmask Netmask
mtu MTU
dhcp DHCP Settings
# set lan network 1 interface lan0
OK
# set lan network 1 ip 172.16.10.67 //set IP address for lan
OK //setting succeed
# set lan network 1 netmask 255.255.0.0
OK
#
…
# config save_and_apply
OK // save and apply current configuration, make you configuration effect

Robustel R2000 Specifications

General

Model	R2000
Category	Network Router
Cellular Connectivity	4G LTE
WAN Ports	1
Ethernet Ports	2
Input Voltage	9-36 VDC
SIM Slots	2
Certifications	CE, FCC, RoHS
Operating Temperature	-40°C to 75°C
