Robustel R2000 User Manual

Robustel R2000 User Guide
RT_UG_R2000_v.3.0.0 July 24, 2017 40 / 124
Confidential
Note: Lan0 cannot be deleted.
You may click to add a new LAN port, or click to delete the current LAN port. Now, click to edit the
configuration of the LAN port. The maximum count is 2.
General Settings @ LAN
Item
Description
Default
Index
Indicate the ordinal of the list.
--
Interface
Show the editing port. Lan1 is available only if it was selected by one of
ETH0~ETH1 in Ethernet > Ports > Port Settings.
--
IP Address
Set the IP address of the LAN port.
192.168.0.1
Netmask
Set the Netmask of the LAN port.
255.255.255.0
MTU
Enter the Maximum Transmission Unit.
1500
The window is displayed as below when choosing “Server” as the mode.

Robustel R2000 Specifications

General

Model	R2000
Category	Network Router
Cellular Connectivity	4G LTE
WAN Ports	1
Ethernet Ports	2
Input Voltage	9-36 VDC
SIM Slots	2
Certifications	CE, FCC, RoHS
Operating Temperature	-40°C to 75°C
