Robustel R2000 User Guide
RT_UG_R2000_v.3.0.0 July 24, 2017 41 / 124
Confidential
The window is displayed as below when choosing “Relay” as the mode.
Click the toggle button to enable/disable the DHCP function.
Select from “Server” or “Relay”.
Server: Lease IP address to DHCP clients which have been
connected to LAN port
Relay: Router can be a DHCP Relay, which will provide a relay
tunnel to solve the problem that DHCP Client and DHCP Server
are not in a same subnet
Define the beginning of the pool of IP addresses which will be leased
to DHCP clients.
Define the end of the pool of IP addresses which will be leased to
DHCP clients.
Define the subnet mask of IP address obtained by DHCP clients from
DHCP server.
Enter the IP address of DHCP relay server.
Define the gateway assigned by the DHCP server to the clients, which
must be on the same network segment with DHCP address pool.
