62 Rockwell Automation Publication 1756-UM004D-EN-P - August 2022
Appendix A ControlLogix Network Device Status Indicators
Figure 11 - 1756-EN2TP (Dual-port Module)
Figure 12 - 1756-EN4TR (Dual-port Module)
(1)
Figure 13 - 1756-ENBT (Single-port Module)
Figure 14 - 1756-EWEB (Single-port Module)
(1) Parallel Redundant Protocol and Redundant Adapter features are not available in the initial release. Check the Product Compatibility and
Download Center (PCDC
) to see if it is available in your firmware revision.
Link Status
Indicators (LINK)
OK Status Indicator
Network Status Indicator (NET)
Module Status Display
Link Status
Indicators (LINK)
Network Status Indicator (NET)
OK Status Indicator
Module Status Display
Parallel Redundant Protocol
Status Indicator
Redundant Adapter Status Indicator
SD Card Status Indicator
VPN
Module Status Display
OK Status Indicator
Network Status Indicator (NET)
Link Status
Indicator (LINK)
Link Status
Indicator (LINK)
Network Status Indicator (NET)
OK Status Indicator
Module Status Display
