Rockwell Automation Publication 1756-UM004D-EN-P - August 2022 11
Chapter 1 ControlLogix EtherNet/IP Network Device Overview
EtherNet/IP Network
The Ethernet Industrial (EtherNet/IP) network protocol is an open industrial-
networking standard that supports both real-time I/O messaging and message
exchange. The EtherNet/IP network uses off-the-shelf Ethernet
communication chips and physical media.
If you need to Select this interface
Control I/O modules and drives
Act as an adapter for I/O on remote EtherNet/IP links
Communicate with other EtherNet/IP devices (messages and HMI)
Bridge EtherNet/IP links to route messages to devices on other networks
1756-EN2F, 1756-EN2FK
1756-EN2T, 1756-EN2TK, 1756-EN2TXT
1756-EN2TP, 1756-EN2TPK, 1756-EN2TPXT
1756-EN2TR, 1756-EN2TRK, 1756-EN2TRXT
1756-EN4TR, 1756-EN4TRK, 1756-EN4TRXT
1756-ENBT, 1756-ENBTK
Support Device Level Ring (DLR) and linear topologies
1756-EN2TR, 1756-EN2TRK, 1756-EN2TRXT
1756-EN3TR, 1756-EN3TRK
1756-EN4TR, 1756-EN4TRK, 1756-EN4TRXT
Support for Parallel Redundancy Protocol
1756-EN2TP, 1756-EN2TPK, 1756-EN2TPXT
1756-EN4TR
(1)
, 1756-EN4TRK
(1)
, 1756-EN4TRXT
(1)
Support for Redundant Adapters
(2)
1756-EN4TR, 1756-EN4TRK, 1756-EN4TRXT
Provide control in environments where temperatures range from -25…+70 C (-13…+158 F)
1756-EN2TPXT
1756-EN2TRXT
1756-EN2TXT
1756-EN4TRXT
Secure access to a control system from within the plant network 1756-EN4TR, 1756-EN4TRK, 1756-EN4TRXT
Use an Internet browser to access tags remotely in a ControlLogix controller
Communicate with other EtherNet/IP or generic Ethernet devices (messaging only; no I/O control)
Bridge EtherNet/IP links to route messages to devices on other networks
1756-EWEB, 1756-EWEBK web server
(1) Starting with firmware revision 4.001.
(2) Redundant Adapters require version 3.001 and higher firmware. See the Product Compatibility and Download Center (PCDC)
for that firmware.
