Rockwell Automation Allen-Bradley 1756-EN2T User Manual

10 Rockwell Automation Publication 1756-UM004D-EN-P - August 2022
Chapter 1 ControlLogix EtherNet/IP Network Device Overview
Table 4 - ControlLogix EtherNet/IP Specifications
(1)
Cat. No.
Firmware
Revision
RSLogix 5000
Software Version
RSLinx®
Software Version
Packet Rate Capacity (packets/
second)
(2)
Support for
Extended
Environment
(3)
Integrated Motion on
the EtherNet/IP
Network Axes
I/O HMI/MSG
1756-ENBT Any 8.02.00 or later 2.30 or later 5000 900 No N/A
1756-EN2F
2.x 15.02.00 or later
2.51 or later
10,000
2000 No
N/A
3.6 or later
18.02.00 or later
(4)
25,000
(5)
Up to 8 axes
supported
(5)
1756-EN2T
2.x or earlier 15.02.00 or later
2.51 or later
10,000
2000 No
N/A
3.6 or later
18.02.00 or later
(4)
25,000
(5)
Up to 8 axes
supported
(5)
1756-EN2TXT
2.x 15.02.00 or later
2.51 or later
10,000
2000 Yes
N/A
3.6 or later
18.02.00 or later
(4)
25,000
(5)
Up to 8 axes
supported
(5)
1756-EN2TP Any
24.00.00 or later
(4)
4.10 or later
25,000
(5)
2000 No
Up to 8 axes
supported
(5)
1756-EN2TPXT 10.x or later 24.00.00 or later 4.10 or later
25,000
(5)
2000 Yes
Up to 8 axes
supported
(5)
1756-EN2TR
2.x 17.01.02 or later 2.55 or later 10,000
2000 No
N/A
5.x or later
18.02.00 or later
(4)
2.56 or later
25,000
(5)
Up to 8 axes
supported
(5)
1756-EN2TRXT 5.028 or later 20.01.00 or later 2.56 or later
25,000
(5)
2000 Yes
Up to 8 axes
supported
(5)
1756-EN3TR 3.6 or later
18.02.00 or later
(4)
2.56 or later
25,000
(5)
2000 No
Up to 128 axes
supported
(5)
1756-EN4TR Any
24.00.00 or later
(6)
4.10 or later
• 50,000 without
CIP Security™
• 25,000 with
integrity
• 15,000 with
integrity and
confidentiality
• 3,700 without CIP
Security
•2,700 with
integrity
•1,700 with
integrity and
confidentiality
No
Up to 256 axes
supported
(5)
1756-EN4TRXT Any
24.00.00 or later
(6)
4.10 or later
• 50,000 without
CIP Security
• 25,000 with
integrity
• 15,000 with
integrity and
confidentiality
• 3,700 without CIP
Security
•2,700 with
integrity
•1,700 with
integrity and
confidentiality
Yes
Up to 256 axes
supported
(5)
(1) Includes the K conformal coating catalog numbers.
(2) I/O numbers are maximums; they assume no HMI/MSG. HMI/MSG numbers are maximums, they assume no I/O. Packet rates vary depending on packet size. For more details, see
Troubleshoot EtherNet/IP Application Technique, publication ENET-AT003
, and the EDS file for a specific catalog number.
(3) Module operates in a broad temperature spectrum, -20…+70 ºC (-4…+158 ºF), and meets ANSI/ISA-S71.04-1985 Class G1, G2 and G3, and cULus, Class 1 Div 2, C-Tick, CE, ATEX Zone 2 and SIL 2
requirements for increased protection against salts, corrosives, moisture/condensation, humidity, and fungal growth.
(4) This version is required to use CIP Sync™ technology, Integrated Motion on the EtherNet/IP Network, or Exact Match keying.
(5) This value assumes the use of a 1756-L8x or a 1756-L7x ControlLogix controller. For a 1756-L6x ControlLogix controller, see ControlLogix Controllers User Manual, publication 1756-UM001
.
(6) CIP Security requires FactoryTalk® Linx version 6.11.00 or later.
