Rockwell Automation Publication 2198-UM005C-EN-P - February 2022 129
Chapter 6 Configure and Start up the Kinetix 5300 Drive System
9. From the Motor Type pull-down menu, choose Rotary Induction.
10. From the motor nameplate or datasheet, enter the phase-to-phase values
for your motor.
For a motor performance datasheet example, see Motor Category
on
page 212. Also see Motor Nameplate Datasheet Entry for Custom Motor
Applications, publication 2198-AT002.
11. Click Apply.
12. Select the Motor Feedback category.
The Motor Feedback Device Specification dialog box appears.
13. From the Type pull-down menu, choose the feedback type appropriate
for your application.
See Configure Feedback Properties
on page 133 for feedback
configuration examples.
14. Click Apply.
