Rockwell Automation Allen-Bradley Kinetix 5300 User Manual

Rockwell Automation Publication 2198-UM005C-EN-P - February 2022 13
Chapter 1
Start
Use this chapter to become familiar with the Kinetix® 5300 drive system and
obtain an overview of the installation configurations.
Topic Page
About the Kinetix 5300 Servo Drive System 14
Drive Hardware and Input Power Configurations 15
Motor and Auxiliary Feedback Configurations 18
Typical Communication Configurations 19
Safe Torque Off Configuration 22
Catalog Number Explanation 23
Agency Compliance 24
