Chapter 4 Commissioning
Drive Circuit Boards
Acronym Production Assembly Part Number Hardware Revision Firmware Revision
ACB 80190-560- —
DPM 80190-580-
OIB L (A,B,C) 80190-099- —
OIBB 80190-600- —
OIB M (A,B,C) 80190-099- —
XIO
(1)
80190-299- —
VSB L 1 81000-199- —
VSB L 2 81000-199- —
VSB M 1 81000-199- —
Operator Interface 2711-KSASL11 PV Firmware
(2)
PV Software
(3)
TFB L 80190-639-
or 80190-539-
—
TFB M 80190-639-
or 80190-539-
—
SCR SPGDB
(1)
80190-219- —
SPS
(1)
80190-799-
IGDPS L (1-3) 80026-044- —
IGDPS M (1-3) 80026-044- —
PS1 (A-F)
(1)
[AC/DC Converter] 80026-520 or 524 - —
PS2 [DC/DC Converter] 81002-440- —
PS4 [24V DC Power supply] —
CPT 80022-069- —
UPS —
Printer —
(1) The drive can have more than one of this circuit board.
(2) PV Firmware is located on a sticker on the back of the unit.
(3) PV Software is located on the main display screen (top-left corner).
